Plan specifications
1,500Sq. ft
3Bedrooms
2Bathrooms
2Stories
30' 0"Width
50' 0"Depth
Slab, Pier or Crawl Space (all three included)Foundation shown
About this plan
A 30 by 50 foot cabin under a single-slope shed roof, 1,500 square feet with three bedrooms and two bathrooms, plus an optional 215 square foot loft. The 30x50 shed roof cabin plans arrive as a PDF plan set.
The lean shed roof
One slope, running the full 30 foot width. Inside, the ceiling rises from eight feet at the low wall to fifteen at the high one, so the living space gets the height and the glazing while the bedrooms stay at a comfortable, cheap-to-heat eight feet.
It is also the simplest roof there is to frame. No ridge board, no valleys, no hip rafters, and every rafter cut identically, which cuts both the labour and the scope for error.
The optional loft
A 215 square foot loft is drawn as an option under the high side. Framed in, it is a fourth sleeping space or an office; left out, the living space keeps its full height. Both versions are in the set, so it is a decision you can make on site.
Practicalities
A large front deck runs along the tall elevation, where the glazing is. There is dedicated washer and dryer space.
Slab, pier and crawl space foundations are all included. An editable CAD file is available as an add-on if you intend to alter the layout.
What you get
A complete construction set, supplied as a PDF:
- Dimensioned floor plans for each level, drawn to scale
- Exterior elevations on all four sides
- Building sections and construction details
- Foundation plan with floor, wall and roof framing layouts
- Electrical layout
- Window and door schedules
- Roof plan with pitch and overhang dimensions
Before you build
Permit requirements depend on your location, site and proposed construction. Your building department determines which drawings, calculations and professional approvals are required, and local review may identify changes needed to the plans. Some departments ask for an engineer’s stamp or a foundation designed around your own soil report; arrange these with a local engineer.
Other plans to compare
If these 30x50 shed roof cabin plans are not quite the right size, browse every design in Cabin, or compare this one with Modern A-Frame Cabin, 20×28 and Hilltop Hideout, 28×28. You may also want to look at Modern Lean Cottage, 30×46.
Common questions
Can I modify these 30x50 shed roof cabin plans?
Often, yes. Common requests include moving a wall, mirroring the layout or adapting the foundation to your site, but what is possible depends on the plan, so ask for a free quote before you buy. Editable CAD files are not available for every plan; email us to confirm availability for this one.
How are the drawings supplied?
Plans are supplied digitally as PDF files. Our Shipping and Delivery Policy explains how and when files are made available.
Are there limits on printing?
No. Print whatever your builder, your subcontractors and your permit submission need.
Rough build-cost guide
$225,000 - $300,000
A simple $150-$200 per sq ft × 1,500 sq ft. Real costs depend on your location, site and finishes. Read the cost guideFloor plans
100%
Preview image. Use + and − to zoom, then scroll to move around. The purchased PDF contains the full-size, dimensioned drawings.
What you get with this plan
- Heated area
- 1,500 sq ft
- Overall size
- 30' 0" wide × 50' 0" deep
- Units
- Imperial (feet and inches)
- Foundation shown
- Slab, Pier or Crawl Space (all three included) (other foundation types are a modification)
- PDF Set
- Printable PDF construction drawings
- CAD Files package
- Editable DWG drawings of the same set (+$150)
- Paper size
- Not yet listed for this plan
- Licence
- Single build. Licence terms
- Delivery
- Digital PDF plan set. Delivery policy
Sheet list
The sheet list for this plan has not been published yet. Email support@planbarn.com and we will send it before you buy.
Not included
- Site plan, and mechanical (HVAC), plumbing or structural engineering calculations unless listed in the sheet list above
- Engineer or architect stamps. Many areas require local review or a stamp before a permit is issued
- Changes for your site, climate or local code. We quote modifications free of charge
Your building department decides what is needed for a permit. Check local requirements before you build.
Plan features
Large Front Deck
8 to 15 ft Ceilings
Optional 215 sq ft Loft
Lean Shed Roof
Washer & Dryer Space
3 Foundation Options
CAD Add-On Available
Questions about this plan
What is included?
The specifications, file formats and licence are listed under “What you get with this plan”. Where the sheet list is not yet published, email us and we will send it before you buy.
Can I modify the plan?
Often, yes. Ask for a free quote and we will confirm whether the change can be made for this plan; the written quote gives the price and an estimated completion time before you commit. Plan modifications
How is the plan delivered?
As a digital PDF plan set. Our delivery policy explains how and when files are made available. Delivery policy
Will it meet my local building code?
Codes are set locally. Your building department, and in many areas a local engineer or architect, must review the plans; some areas require a stamp. Budget for this before you build.
Can I get a refund?
Digital files cannot be returned. Where cancellation rights apply you can normally cancel within 14 days, unless you agreed for supply to begin immediately. If a file is faulty, incomplete or does not match this page, we repair or replace it, and refund you where that is not possible. Returns and Refunds Policy
Can I build it more than once?
The standard licence covers one build. Email us for a multi-build licence. Plan licence
Do I need an account?
No. Guest checkout is available; your receipt and download link go to the email address you enter.
