Cabin1 / 5
Exterior and interior renderings are illustrative. Furniture, landscaping and finishes are not part of the plan set unless listed.
Plan specifications
1,380Sq. ft
3Bedrooms
2Bathrooms
2Stories
30' 0"Width
46' 0"Depth
Slab, Pier or Crawl SpaceFoundation shown
About this plan
A 30 by 46 foot cottage under a shallow shed roof, 1,380 square feet with three bedrooms and two bathrooms, plus a 145 square foot sleeping loft. These 30x46 shed roof house plans come as a complete PDF set.
A low ridge by design
The roof pitch is 3 in 12 and the ridge sits at 16 feet 7 inches. That is deliberately low. Height restrictions catch more self-builders than any other rule, particularly on rural lots with covenants and in areas with view protections, and a 16 foot 7 inch ridge clears almost all of them.
Inside, the single slope still gives you ceilings from eight feet up to fifteen feet six, so keeping the outside low costs nothing in the volume you actually experience.
How it is arranged
Three bedrooms and two bathrooms on the main level, with a 145 square foot sleeping loft above for a fourth berth or a quiet room. A large front deck runs along the tall elevation where the glazing is, and there is dedicated washer and dryer space.
Foundation options
Slab, pier and crawl space are all drawn and detailed. Which one is cheapest depends on frost depth and water table, so price all three locally before you commit.
What you get
A complete construction set, supplied as a PDF:
- Dimensioned floor plans for each level, drawn to scale
- Exterior elevations on all four sides
- Building sections and construction details
- Foundation plan with floor, wall and roof framing layouts
- Electrical layout
- Window and door schedules
- Roof plan with pitch and overhang dimensions
Before you build
Permit requirements depend on your location, site and proposed construction. Your building department determines which drawings, calculations and professional approvals are required, and local review may identify changes needed to the plans. Some departments ask for an engineer’s stamp or a foundation designed around your own soil report; arrange these with a local engineer.
Other plans to compare
If these 30x46 shed roof house plans are not quite the right size, browse every design in Cottage, or compare this one with Modern Cottage, 40×60 and Tulip Cottage Craftsman Bungalow. You may also want to look at Modern Cabin with Loft, 35×35.
Common questions
Can I modify these 30x46 shed roof house plans?
Often, yes. Common requests include moving a wall, mirroring the layout or adapting the foundation to your site, but what is possible depends on the plan, so ask for a free quote before you buy. Editable CAD files are not available for every plan; email us to confirm availability for this one.
How do I receive the drawings?
Plans are supplied digitally as PDF files. Our Shipping and Delivery Policy explains how and when files are made available.
How many copies can I print?
As many as the build needs, for your contractor, your subcontractors and your permit application.
Rough build-cost guide
$207,000 - $276,000
A simple $150-$200 per sq ft × 1,380 sq ft. Real costs depend on your location, site and finishes. Read the cost guideFloor plans
100%
Preview image. Use + and − to zoom, then scroll to move around. The purchased PDF contains the full-size, dimensioned drawings.
What you get with this plan
- Heated area
- 1,380 sq ft
- Overall size
- 30' 0" wide × 46' 0" deep
- Units
- Imperial (feet and inches)
- Foundation shown
- Slab, Pier or Crawl Space (other foundation types are a modification)
- PDF Set
- Printable PDF construction drawings
- CAD Files package
- Editable DWG drawings of the same set (+$150)
- Paper size
- Not yet listed for this plan
- Licence
- Single build. Licence terms
- Delivery
- Digital PDF plan set. Delivery policy
Sheet list
The sheet list for this plan has not been published yet. Email support@planbarn.com and we will send it before you buy.
Not included
- Site plan, and mechanical (HVAC), plumbing or structural engineering calculations unless listed in the sheet list above
- Engineer or architect stamps. Many areas require local review or a stamp before a permit is issued
- Changes for your site, climate or local code. We quote modifications free of charge
Your building department decides what is needed for a permit. Check local requirements before you build.
Plan features
3:12 Roof Pitch
16 ft 7 in Ridge
8 to 15 ft 6 in Ceilings
145 sq ft Sleeping Loft
Large Front Deck
Washer & Dryer
3 Foundation Options
Questions about this plan
What is included?
The specifications, file formats and licence are listed under “What you get with this plan”. Where the sheet list is not yet published, email us and we will send it before you buy.
Can I modify the plan?
Often, yes. Ask for a free quote and we will confirm whether the change can be made for this plan; the written quote gives the price and an estimated completion time before you commit. Plan modifications
How is the plan delivered?
As a digital PDF plan set. Our delivery policy explains how and when files are made available. Delivery policy
Will it meet my local building code?
Codes are set locally. Your building department, and in many areas a local engineer or architect, must review the plans; some areas require a stamp. Budget for this before you build.
Can I get a refund?
Digital files cannot be returned. Where cancellation rights apply you can normally cancel within 14 days, unless you agreed for supply to begin immediately. If a file is faulty, incomplete or does not match this page, we repair or replace it, and refund you where that is not possible. Returns and Refunds Policy
Can I build it more than once?
The standard licence covers one build. Email us for a multi-build licence. Plan licence
Do I need an account?
No. Guest checkout is available; your receipt and download link go to the email address you enter.
Not ready to buy yet?
Three things you can do right now, all free.
Get a modification quoteMove a wall, add a garage, flip the plan. Tell us the change and we will confirm whether it can be made and quote it at no cost.Request a free quote →Check what it costs to buildCurrent per-square-foot construction costs, broken down by region and finish level.Read the cost guide →Ask a real questionNot sure this plan suits your lot, your budget or your local code? Ask before you spend anything.Ask us →
