Cabin1 / 5
Exterior and interior renderings are illustrative. Furniture, landscaping and finishes are not part of the plan set unless listed.
Plan specifications
1,675Sq. ft
3Bedrooms
2Bathrooms
2Stories
35' 0"Width
35' 0"Depth
Crawl SpaceFoundation shown
About this plan
A 35 foot square lake house, 1,675 square feet over two levels with three bedrooms and two bathrooms. The layout is mirrored, and a large patio runs off the living space. The full set of lake house plans downloads straight after payment.
The mirrored layout
A mirrored plan is symmetrical about its centre line, which on a lake lot is a practical advantage rather than a stylistic one. It means the house can be turned to face the water whichever side the water happens to be on, without redrawing anything or ending up with the kitchen window facing the view and the living room facing the road.
Symmetry also simplifies framing, since the two halves repeat.
Built for the view
Ceilings are nine feet throughout and the ridge reaches 26 feet 10 inches under a 10 in 12 gable. The second floor is 450 square feet, kept deliberately small so that most of the accommodation sits on the main level where the outlook is.
The large patio is the room you will use most between May and September.
Foundation
Drawn for a crawl space, which suits waterside ground: the floor stays clear of damp, and services remain reachable without breaking into concrete.
What you get
The download is a full construction set: dimensioned floor plans for each level, exterior elevations on all four sides, building sections and construction details, a foundation plan with floor, wall and roof framing layouts, an electrical layout, window and door schedules, and a roof plan with pitch and overhang dimensions. It arrives as a PDF once payment is confirmed.
Before you build
Permit requirements depend on your location, site and proposed construction. Your building department determines which drawings, calculations and professional approvals are required, and local review may identify changes needed to the plans. Some departments ask for an engineer’s stamp or a foundation designed around your own soil report; arrange these with a local engineer.
Other plans to compare
If these lake house plans are not quite the right size, browse every design in Cabin, or compare this one with Lean Cabin, 24×36 and Willow Cabin, 26×34.
Common questions
Can I modify these lake house plans?
Often, yes. Common requests include moving a wall, mirroring the layout or adapting the foundation to your site, but what is possible depends on the plan, so ask for a free quote before you buy. Editable CAD files are not available for every plan; email us to confirm availability for this one.
How do I get the files?
Plans are supplied digitally as PDF files. Our Shipping and Delivery Policy explains how and when files are made available.
Can my builder have a copy?
Yes. Print as many sets as your contractor, your trades and your building department require.
Rough build-cost guide
$251,250 - $335,000
A simple $150-$200 per sq ft × 1,675 sq ft. Real costs depend on your location, site and finishes. Read the cost guideFloor plans
100%
Preview image. Use + and − to zoom, then scroll to move around. The purchased PDF contains the full-size, dimensioned drawings.
What you get with this plan
- Heated area
- 1,675 sq ft
- Overall size
- 35' 0" wide × 35' 0" deep
- Units
- Imperial (feet and inches)
- Foundation shown
- Crawl Space (other foundation types are a modification)
- PDF Set
- Printable PDF construction drawings
- CAD Files package
- Editable DWG drawings of the same set (+$150)
- Paper size
- Not yet listed for this plan
- Licence
- Single build. Licence terms
- Delivery
- Digital PDF plan set. Delivery policy
Sheet list
The sheet list for this plan has not been published yet. Email support@planbarn.com and we will send it before you buy.
Not included
- Site plan, and mechanical (HVAC), plumbing or structural engineering calculations unless listed in the sheet list above
- Engineer or architect stamps. Many areas require local review or a stamp before a permit is issued
- Changes for your site, climate or local code. We quote modifications free of charge
Your building department decides what is needed for a permit. Check local requirements before you build.
Plan features
10:12 Gable Pitch
26 ft 10 in Ridge
9 ft Ceilings
450 sq ft Second Floor
Large Patio
Mirrored Layout
Questions about this plan
What is included?
The specifications, file formats and licence are listed under “What you get with this plan”. Where the sheet list is not yet published, email us and we will send it before you buy.
Can I modify the plan?
Often, yes. Ask for a free quote and we will confirm whether the change can be made for this plan; the written quote gives the price and an estimated completion time before you commit. Plan modifications
How is the plan delivered?
As a digital PDF plan set. Our delivery policy explains how and when files are made available. Delivery policy
Will it meet my local building code?
Codes are set locally. Your building department, and in many areas a local engineer or architect, must review the plans; some areas require a stamp. Budget for this before you build.
Can I get a refund?
Digital files cannot be returned. Where cancellation rights apply you can normally cancel within 14 days, unless you agreed for supply to begin immediately. If a file is faulty, incomplete or does not match this page, we repair or replace it, and refund you where that is not possible. Returns and Refunds Policy
Can I build it more than once?
The standard licence covers one build. Email us for a multi-build licence. Plan licence
Do I need an account?
No. Guest checkout is available; your receipt and download link go to the email address you enter.
Not ready to buy yet?
Three things you can do right now, all free.
Get a modification quoteMove a wall, add a garage, flip the plan. Tell us the change and we will confirm whether it can be made and quote it at no cost.Request a free quote →Check what it costs to buildCurrent per-square-foot construction costs, broken down by region and finish level.Read the cost guide →Ask a real questionNot sure this plan suits your lot, your budget or your local code? Ask before you spend anything.Ask us →
Plan #17853
What you actually receive
Inside the Long Creek Lake House, 35x35 plan set
