Cabin1 / 5
Exterior and interior renderings are illustrative. Furniture, landscaping and finishes are not part of the plan set unless listed.
Plan specifications
1,145Sq. ft
2Bedrooms
1Bathroom
2Stories
24' 0"Width
36' 0"Depth
Slab or Pier/PostFoundation shown
About this plan
A 24 by 36 foot Nordic A-frame, 1,145 square feet over two levels, two bedrooms and one bathroom, with a 280 square foot loft reached by a spiral staircase. Drawn to sleep three or four. The full set of 24x36 a-frame plans downloads straight after payment.
The spiral staircase
A spiral stair occupies roughly a third of the floor area a conventional straight flight needs. In a building 24 feet wide with a double-height living space running through it, that is the difference between a stair that dominates the room and one that sits in a corner of it.
It is also the only stair type that works well under a steeply pitched A-frame roof, because it climbs within its own diameter rather than needing a long run of headroom.
How it is arranged
The living space is double height, open to the 280 square foot loft above. Two bedrooms and a bathroom complete the plan, and a front deck extends the living area outdoors. Washer and dryer space is drawn in.
Structure and foundation
Rated for 115 mile per hour winds, which on a tall, steep A-frame matters more than it does on a low building, because the gable presents a large surface to the weather.
Drawn for a slab or for pier and post, so it suits both level and uneven ground.
What you get
The download is a full construction set: dimensioned floor plans for each level, exterior elevations on all four sides, building sections and construction details, a foundation plan with floor, wall and roof framing layouts, an electrical layout, window and door schedules, and a roof plan with pitch and overhang dimensions. It arrives as a PDF once payment is confirmed.
Before you build
Permit requirements depend on your location, site and proposed construction. Your building department determines which drawings, calculations and professional approvals are required, and local review may identify changes needed to the plans. Some departments ask for an engineer’s stamp or a foundation designed around your own soil report; arrange these with a local engineer.
Other plans to compare
If these 24x36 a-frame plans are not quite the right size, browse every design in A-Frame, or compare this one with Large Modern A-Frame Cabin, 36×58 and Modern A-Frame Cabin, 24×36.
Common questions
Can I modify these 24x36 a-frame plans?
Often, yes. Common requests include moving a wall, mirroring the layout or adapting the foundation to your site, but what is possible depends on the plan, so ask for a free quote before you buy. Editable CAD files are not available for every plan; email us to confirm availability for this one.
How are the drawings supplied?
Plans are supplied digitally as PDF files. Our Shipping and Delivery Policy explains how and when files are made available.
Are there limits on printing?
No. Print whatever your builder, your subcontractors and your permit submission need.
Rough build-cost guide
$171,750 - $229,000
A simple $150-$200 per sq ft × 1,145 sq ft. Real costs depend on your location, site and finishes. Read the cost guideFloor plans
100%
Preview image. Use + and − to zoom, then scroll to move around. The purchased PDF contains the full-size, dimensioned drawings.
What you get with this plan
- Heated area
- 1,145 sq ft
- Overall size
- 24' 0" wide × 36' 0" deep
- Units
- Imperial (feet and inches)
- Foundation shown
- Slab or Pier/Post (other foundation types are a modification)
- PDF Set
- Printable PDF construction drawings
- CAD Files package
- Editable DWG drawings of the same set (+$150)
- Paper size
- Not yet listed for this plan
- Licence
- Single build. Licence terms
- Delivery
- Digital PDF plan set. Delivery policy
Sheet list
The sheet list for this plan has not been published yet. Email support@planbarn.com and we will send it before you buy.
Not included
- Site plan, and mechanical (HVAC), plumbing or structural engineering calculations unless listed in the sheet list above
- Engineer or architect stamps. Many areas require local review or a stamp before a permit is issued
- Changes for your site, climate or local code. We quote modifications free of charge
Your building department decides what is needed for a permit. Check local requirements before you build.
Plan features
Double-Height Ceiling
280 sq ft Loft
Spiral Staircase
Front Deck
115 MPH Wind Rated
Washer & Dryer
Sleeps 3-4
Questions about this plan
What is included?
The specifications, file formats and licence are listed under “What you get with this plan”. Where the sheet list is not yet published, email us and we will send it before you buy.
Can I modify the plan?
Often, yes. Ask for a free quote and we will confirm whether the change can be made for this plan; the written quote gives the price and an estimated completion time before you commit. Plan modifications
How is the plan delivered?
As a digital PDF plan set. Our delivery policy explains how and when files are made available. Delivery policy
Will it meet my local building code?
Codes are set locally. Your building department, and in many areas a local engineer or architect, must review the plans; some areas require a stamp. Budget for this before you build.
Can I get a refund?
Digital files cannot be returned. Where cancellation rights apply you can normally cancel within 14 days, unless you agreed for supply to begin immediately. If a file is faulty, incomplete or does not match this page, we repair or replace it, and refund you where that is not possible. Returns and Refunds Policy
Can I build it more than once?
The standard licence covers one build. Email us for a multi-build licence. Plan licence
Do I need an account?
No. Guest checkout is available; your receipt and download link go to the email address you enter.
Not ready to buy yet?
Three things you can do right now, all free.
Get a modification quoteMove a wall, add a garage, flip the plan. Tell us the change and we will confirm whether it can be made and quote it at no cost.Request a free quote →Check what it costs to buildCurrent per-square-foot construction costs, broken down by region and finish level.Read the cost guide →Ask a real questionNot sure this plan suits your lot, your budget or your local code? Ask before you spend anything.Ask us →
